Model:XQRY-120

Model:XQRY-160

电加热功率electric heating power

10KW

12KW

工作温度范围working temperature range

160～180℃

160～180℃

最高温度Max.temperature

240℃

240℃

仪表控制温度精度误差instrument control temperature accuracy error

±2℃

±2℃

工件温度误差workpiece temperature error(within 1 meter)

±10℃

±10℃

液压系统工作压力范围hydraulic system working pressure range

3～6Mpa

3～6Mpa

液压压头数量hydraulic press head qty.

6

8

液压压头压力范围hydraulic press head pressure range

1000-2000 kgf

1000-2000 kgf

线圈单边压紧力范围coil single edge pressing force range (three press heads resultant force)

3000-6000kgf

4000-8000kgf

线圈开档W范围coil open mouth W field

190～650mm

200～1000mm

线圈直线边L3长度范围coil straight edge length L3 range

≤1200mm

≤1600mm

线圈最大截面coil max.section

32×65mm2

32×65mm2

模具总长mould total length

1650mm

2000mm

发热管长度heating tube length

1450mm

1850mm

有效发热区长度effective heating area length

1200mm

1700mm
